High-Speed & High-Current Servo Solution
High-speed servo applications often require a unique set of capabilities that are beyond what’s available in most of today’s drives. Fortunately, ESI’s Roadwind line of drives is designed for exactly this area, offering unmatched power density, speed ratings, and packaged in ESI Motion’s ruggedized casing.
An Integrated Drive System For Demanding Conditions
On the cutting edge of servo technology, the Roadwind series satisfies the most speed-hungry applications. Roadwind operates at 12V to 150V, -40°C to 71°C and is ideal for ground defense, aerospace autonomous vehicles, racing and specialized industrial applications. The fully-integrated Roadwind system combines all crucial functions into one compact ruggedized case.
Let Us Modify The Roadwind Exactly To Your Specification
Our rugged servo drives will get your attention, but our engineering team and personalized service is what truly sets us apart. Our team is committed to helping you ensure success by providing dedicated support to your team. Find out why ESI Motion is a world leader today!
Feature highlights include:
- Incredible high-speed performance up to 300,000 RPM
- High-density DSP controller
- Active inrush limiter
- Resolver, encoder, sensorless, hall & BiSS-C feedback
- Configurable, user-friendly GUI with enhanced data collection capability
Applications:
- Actuator control
- Traction motor
- Camera stabilization
- Laser beam director
- Hybrid vehicles
150+ Configurations
Specifications
| BUS VOLTAGE (DC) | 12V – 150V |
|---|---|
| PEAK MOTOR CURRENT | Up to 200A |
| OUTPUT POWER MAX | 15kW |
| TEMPERATURE | -40ºC to 71ºC |
| ELECTRICAL SPEED MAX | Up to 300,000 RPM |
| WEIGHT | 8.1 lbs (3.7kg) |
| MOTOR TYPES | DC Brushless, Brushed and Induction |
| FEEDBACK OPTIONS | Sensorless, Encoder, Resolver, Hall & BiSS-C |
| COOLING OPTIONS | Chassis, Fan or Liquid |
| PACKAGING | Ruggedized |
| SIZE | 13.8” L x 7.0” W x 3.1” H |
